DGD-5005 Pentek Whole House Filter Replacement Cartridge

SKU
PENTEK-DGD-5005
Price $20.99 List Price Price $29.99 Save 30%
Availability: In Stock
Fits Pentek Big Blue and other heavy-duty filter housings
Choose a quantity
  • 1filter$20.99
  • 6filters$18.89each
  • 12filters$15.74each
  • 20filters$15.10each
Available Add-Ons
x

SKU: PENTEK-HFPP-PR10 › See more product details

Pentek HFPP-1-PR10 Whole House 10 inch Filter Housing

Pentek Big Blue 1-inch Inlet/Outlet Housing for 10 x 4.5-inch Water Filters
Add: $68.99 $47.99
  • Dual-Gradient Density (DGD) offers a 50 micron pre-filter and 5 micron post-filter in one cartridge
  • Effective filter depth is increased to a full 233% of standard spun-polypropylene or string-wound filters
  • Spun fibers form a true gradient density from outer to inner surfaces
  • Manufactured from pure 100% polypropylene
› See more product details
Save $8.25 with a Tier1 Brand
Comparable Filter
View Filter Value Comparison
  • Dual-Gradient Density (DGD) offers a 50 micron pre-filter and 5 micron post-filter in one cartridge
  • Effective filter depth is increased to a full 233% of standard spun-polypropylene or string-wound filters
  • Spun fibers form a true gradient density from outer to inner surfaces
  • Manufactured from pure 100% polypropylene
Save $8.25 with a Tier1 Brand
Comparable Filter
View Filter Value Comparison
The PENTEK-DGD-5005 heavy duty filter cartridge is manufactured from 100% pure polypropylene and is sized for use in Big Blue and other heavy-duty filter housings. The DGD-5005 cartridge uses a performance enhancing dual-gradient density filtration to achieve up to three times the dirt-holding capacity of similar size sediment cartridges. The increased depth of the filter media provides for very high particulate reduction efficiencies and makes it an excellent choice for all residential, rural, municipal and commercial applications.
More Information
Package Qty 1
Used In Brands Pentek
Manufacturer's Id DGD-5005
UPC 051678357439
Advertised Size (in) 10 x 4-1/2
Actual Size (in) 10 inches (length) x 4 1/2 inches (outside diameter)
Actual Size (cm) 25.4 x 11.43
Outside Diameter (inches) 4.5
Media Type Sediment Filter
Media Spun Wound Polypropylene
Primary Filter Media Polypropylene
Filter Life (months) Filter's should be replaced based on usage and filter condition. Filter life is an estimation of expected performance based on typical filtration conditions.x Filter's should be replaced based on usage and filter condition. Filter life is an estimation of expected performance based on typical filtration conditions.x 6 months
Micron Rating (Nominal) The smallest size at which particles are retained by the filter. One micron is equivalent 1/1000th of a millimeter.x The smallest size at which particles are retained by the filter. One micron is equivalent 1/1000th of a millimeter.x 5
Operating Temperature (°F) 40 - 145
Operating Temperature (°C) 4.4 - 62.8
Flow Rate (gpm) Flow rate is the volume of water that passes through a filtration system measured in gallons per minute. A filter's flow rate indicates the maximum recommened flow for optimum filter performance. x Flow rate is the volume of water that passes through a filtration system measured in gallons per minute. A filter's flow rate indicates the maximum recommened flow for optimum filter performance. x 10
Flow Rate (lpm) 37.854
Color White
Country of Manufacture China
Includes One Dual Density Pentek DGD-5005 Sediment Water Filter
Additional Information Pre-Filter Rating: 50 Microns, Post-Filter Rating: 5 Micron
Certifications Voluntary national standards that establish minimum requirements for the safety and performance of filtration equipment.x Voluntary national standards that establish minimum requirements for the safety and performance of filtration equipment.x NSF/ANSI Standard 42

Reduced Contaminants

The PENTEK-DGD-5005 reduces the following contaminants:

  • Dirt
  • Extra Fine Sand
  • Fine Sand
  • Rust and Corrosion
  • Sand
  • Sediment
  • Silt

The PENTEK-DGD-5005 is comparable with the following part numbers

155357-43 355217-43
DGD-5005 PENTEK-DGD-5005
WDGD-5005 WDGD 5005

User Guide

Instructions

  1. Turn off water supply. Press red pressure-relief button (if present).
  2. Unscrew housing. Remove large o-ring, wipe clean and set aside.
  3. Discard used filter cartridge. Wash housing with dish soap and warm water using a nonabrasive sponge or cloth. Rinse thoroughly.
  4. Fill 1/3 with water. Add about 1 tablespoon of bleach and scrub to disinfect. Rinse thoroughly.
  5. Lubricate o-ring with clean silicone grease. Change o-ring if any damage cuts or degradation are present. Insert o-ring in groove.
  6. NOTE: This step is important to ensure a proper housing seal. Make certain the o-ring is seated level in the groove.
  7. Insert new filter cartridge.
  8. Screw housing onto the cap and hand-tighten. Do not over tighten. Make sure cap standpipe slips into cartridge.
  9. Turn on water supply. Press pressure-relief button (if present). Check for leaks before leaving installation.
