S810-QL Lamp/ Quartz Sleeve Combo Pack by Viqua

VIQUA-S810-QL

S810-QL Lamp/ Quartz Sleeve Combo Pack by Viqua

.price-ui--loading { display: block !important; opacity: 1 !important; }

$172.00

UV lamp and Quartz sleeve combination is ideal for full system refurbish
Easy do it yourself replacement
Reduces health risks due to contaminants in water
Low maintenance UV system replacements

format_list_bulleted Features & Specs

Package Qty: 1

Manufacturer: Viqua

UPC: 773058100908

Media: Ultraviolet Light

Brand: Viqua

description Instructions

Close main water supply to the UV System, and then open a tap downstream of the UV System to release pressure.
Disconnect main power source and allow the unit to cool for 10 minutes. Note: Ensure there is no other power source connected such as, Solenoid Junction Box.
Remove the UV lamp connector and the UV lamp
(SEE STEP 7-9) Re-insert the new UV lamp inside the quartz sleeve. Attach the connector to the UV lamp and note that the connector will only allow correct installation in one position. Place and tighten the UV lamp connector.
Plug the unit back to the power source. Reset the end of lamp timer alarm back to 365 days.
Close the downstream tap once the UV chamber is filled with water, and inspect for any leakages.
(Quartz Sleeve) Remove the top retaining nut and O-ring. Remove the bottom retaining nut, Spring and loosen the O-ring to drain the water. Remove the quartz sleeve from the UV chamber.
Clean the quartz sleeve with a cloth soaked in CLR, vinegar or some other mild acid and then rinse with water.
Re-insert the quartz sleeve with O-ring(s), Spring, and retaining nut(s). Hand tighten the retaining nut(s), taking care not to over-tighten.

warning_amber Contaminants Reduced

Bacteria

Cryptosporidium

Cysts

Ecoli

Giardia

Viruses

filter_alt Filter Life

Filter Life (months): 12 months

warning

Prop65 warning applies to products that contain carbon media. Click here for more details

WARNING: This product can expose you to chemicals including arsenic, which is known to the State of California to cause cancer and birth defects, or other reproductive harm. For more information go to www.p65warnings.ca.gov

compare_arrows

help Product Details

The S810-QL Lamp/ Quartz Sleeve Combo Pack by Viqua includes one replacement UV lamp and one replacement UV quartz sleeve. This offer includes the lamp and quartz sleeve replacement for the S8Q-PA system. The quartz sleeve protects the UV lamp from being in contact with your water and from build up of small matter in water with use. The sleeve should be cleaned about every three months to ensure that the system continues to operate at full efficiency, when the sleeve can no longer be cleaned of the material film that develops with use it must be replaced. The lamp itself has an average filter life of approximately twelve months, depending on your system various controllers (with this system the BA-ICE-S Viqua UV Disinfection System Controller) and sensors can be installed to measure light given off to monitor status and alert you when it it time for a replacement. Enjoy the continuing clarity of your water by investing in the S810-QL Lamp/ Quartz Sleeve Combo Pack by Viqua today!

	S810-QL Lamp/ Quartz Sleeve Combo Pack by Viqua$172.00 View details	USWF Replacement for VIQUA S810-QL UV Lamp/Sleeve Combo \| Fits the VIQUA S8Q, SV8Q-PA, & SSM-37 Series UV SystemsFrom $75.92 View details
Product Price	$172.00	$75.92
Product SKU	VIQUA-S810-QL	USWF_109042
Warranty Guarantee	—	One (1) Year Limited Warranty
Includes	—	USWF-140109 lamp, USWF-350042 sleeve, and 4 o-rings
